MakerBee Version 2.2 CNC Machine – 1000 x 1500mm

We are proud to now offer the MakerBee Version 2.2 CNC Machine for sale – 1000 x 1500mm by Open Source Mechatronics. This kit is the latest version available including a new Tension System to minimize Lead Screw ‘Whip’ This is the Open Source Mechatronics’ kit for the famous Open Source MakerBee CNC Machine. The MakerBee was originally designed by Ryan Lock of Ooznest UK. It is a super strong, accurate and easy-to-assemble CNC machine. Based on C-Beam, V-Slot, Xtreme Solid V-Wheels and TR8x8(P2) Leadscrews it is strong, accurate and reliable. It has been carefully designed and can accurately cut foams, woods, plastics and aluminium to 0.1-0.2mm accuracy or better. Functional engineering parts, toys, signs or anything else that can be imagined, can be made on the MakerBee CNC Machine. PLEASE NOTE: This kit includes 4 x NEMA 23 Stepper Motors as standard!   Dimension Details: Travel (Cutting Area):    – X-Axis: 800mm    – Y-Axis: 1270mm    – Z-Axis: 122mm (85mm cutting depth with a 12mm baseboard) Workable Material Height (max): 85mm (with a 12mm baseboard) Drive System: TR8x8(P2) ACME Lead Screw Machine Accuracy: 0.05mm – 0.10mm Footprint: 1000mm x 1500mm (not including motors) Compatible Material for Cutting/Milling: Aluminium Hard Wood Soft Wood Plexi Glass Delrin HDPE Foam Kit Includes (Bill of Materials): PLATES 1 Y Plate Left 1 Y Plate Right 2 Y Plate Inner 2 Y End Plate Left 2 Y End Plate Right 1 X Plate Front 1 X Plate Back 1 Z Motor Mount 1 Z Axis Bottom 1 Z Plate 4 End Cap EXTRUSION 2 2040 – 915mm 2 2040 – 995mm 1 2040 – 1000mm 3 2080 – 1460mm 1 C-Beam – 250mm 1 C-Beam – 1000mm 2 C-Beam – 1500mm MOTION 48 Xtreme Solid V Wheel Kit 1 X-Axis ACME Lead Screw – 1057mm 2 Y-Axis ACME Lead Screw – 1557mm 1 Z Axis ACME Lead Screw – 281mm 1 Anti-Backlash Nut Block 6 ACME Nut Block 8 688zz bearing 6 F8-16M Thrust Bearing 4 6.35x8mm Flexible Coupling BRACKETS 8 Angle Corner Bracket 8 Triple L Bracket SPACERS 21 Eccentric Spacer – 6mm x 10mm Hex 14 Aluminum Spacer – 3mm 39 Aluminum Spacer – 6mm 21 Aluminum Spacer – 9mm 16 Aluminum Spacer – 40mm 14 Precision Shim – 10 x 5.2 x 1mm 8 Presision Shim – 10 x 8 x 1mm HARDWARE 14 Lock Collar – 8mm 80 T-Nut – M5 53 Nylon Lock Nut – M5 92 Low Profile Screw – 8mm 24 Low Profile Screw – 12mm 40 Low Profile Screw – 15mm 8 Low Profile Screw – 20mm 14 Low Profile Screw – 25mm 6 Low Profile Screw – 30mm 4 Low Profile Screw – 50mm 12 Low Profile Screw – 55mm 21 Low Profile Screw – 60mm 25 Drop-in T-Nut – M5 1 Lead Screw Tensioning Tool ELECTRONICS 4 Nema 23 Stepper Motor 1.26N.m Don’t forget to check out the great value Add-On Packs for this kit!
