Vectric Cut2D – Pro

CNC manufacturing can now be a more enjoyable and productive experience thanks to Vectric. Vectric Cut2D – Pro gives you all the functionality of Cut2D Desktop, with extra features such as an unlimited job and tool path size, true shape nesting and job set-up sheets.   This software is aimed at production level CNC applications and just like Cut-2D – Desktop, this software includes a wide array of tools for 2D design, editing and allows for an efficient 2D toolpath calculation. Features Ability to import 2D vector files and bitmap images from other programs Complete set of 2D Design and Layout Tools Single Sided & Double Sided Job Types 2D Toolpaths: Profiling, Pocketing, Drilling, Inlays, Quick Engraving and Thread Milling Toolpath Optimized Clearance Tools in Pocketing Ability to simulate the toolpaths before cutting Vast Tool Database Support for add-on gadgets Ability to Merge Toolpaths Unlimited job and toolpath size Key Strengths of Cut2D – Pro   No Size Limit Our VCarve Pro and Cut2D Pro allows you to work with any job size meaning that there are no limitations to the size you want to work with.     Basic Dimensioning The dimensioning tools allows you to create a variety of different types of measurements on your drawing. These can be oriented in any direction or fixed horizontally or vertically. There are also options to add angular and arc dimensions. You can control the text height, font number of decimal places and position for each one. Dimensions can be snapped to vectors, guidelines and the corners or mid-points of each side of your work area. Vector Layout In addition to the editing tools the software also has tools to let you layout parts either in a rectangular array to create a grid of objects or in a circular array to create symmetrical layouts around a center point. When laying out a grid you can adjust mirroring options and shift alternate rows and columns to make more complex layout patterns. Vector shapes can also be pasted along the path of another vector by specifying the distance between each copy or just fitting a specific number on the guiding object. Estimated Machining Times To help estimate how long toolpaths will take to cut the software will calculate a time based on the length of the toolpath and the specified feeds and speeds that have been entered for the selected tool. This can be tweaked by the operator by editing the ‘scale factor’ so over time a value can be optimized based on actual machine performance to ensure the estimate is as close as possible to the actual cutting time. Product Video Have a look at what you can do with Cut2D – Pro in the video below! Additional Information and Support Learn more about Cut2D – Pro features and lots more here. Have a look at the vast Vectric community including support forums  here. Get professional Vectric support here. Find out about System Requirements here. Training/Tutorial videos can be found here. Please Note All Vectric Products are ONLY compatible with the Windows Operating System Software is non-refundable – Please try it before you buy here Software Fulfillment: Please note that these licenses are manually applied and issued by our staff during business hours. Allow up to 1 business day to receive your license. Inquiries: For any questions or assistance, feel free to reach out to us through our Contact Us page.
