Lead CNC Machine V2 – 1000 x 1000

What is a Mechanical Kit?   The mechanical kit is the foundation of your CNC Machine. A mechanical kit includes all the mechanical components needed to build your CNC Machine; All the screws, nuts, wheels, plates,  etc. A Mechanical Kit is a perfect choice if you plan on bringing your own CNC Controller or other Electronics. CNC Add-Ons are required to complete a CNC Machine. These include the electronic system that will control the machine, cable management, and the tool that will be mounted to the machine. About the Lead The Lead CNC Machine was originally designed by Mark Carew and the design is licensed under CC – Attribution – CC BY. This is the Maker Store kit Version 2 based on his design. Lead Version 2 is a super-strong, accurate, and easy to assemble CNC machine, made using off the shelf parts with easily customizable options such as the High Z Mod to increase the working Height. It has been designed to accurately cut foams, woods, plastics and aluminium to 0.05-0.10mm accuracy or better. Functional engineering parts, toys, signs or anything else that can be imagined, can be made on the Lead CNC Machine. The Maker Store kit has a couple of small differences from the design published by Mark Carew. Most notably are the use of Black Corner Connectors in place of Cast Brackets in order to increase rigidity and a tensioning kit to eliminate lead screw whip. Dimension Details: Travel (Cutting Area):    – X Axis: 730mm    – Y Axis: 810mm    – Z Axis: approx 100mm Workable Material Height (max): approx. 50mm (with a 12mm base board) Drive System: TR8x8(P2) ACME Lead Screw Machine Accuracy: 0.05mm – 0.10mm Footprint: 1000mm x 1000mm (not including motors) Compatible Material for Cutting/Milling: Aluminum Hard Wood Soft Wood Plexi Glass Delrin HDPE Foam Kit Includes (Bill of Materials):   QTY Description Part Number 8 688Z Ball Bearing – 8x16x5 BEAR-688Z 18 90 degree Angle Corner Connector (V-Slot) BRAC-90ANG 6 Endcap – 2040 BRAC-ENDCAP-2040 8 Universal L Brackets – Double – Black BRAC-L2 – Black 3 8mm Metric Lead Screw / ACME – 1040mm HARD-ACME-8-1070 1 8mm Metric Lead Screw / ACME – 290mm HARD-ACME-8-290 1 Anti-Backlash Nut Block HARD-ACME-8-ANTIB-BLOCK 6 8mm Acme Nut Block HARD-ACME-8-BLOCK 14 Lock Collar HARD-COLL-8MM 4 6.35mm x 8mm Flexible Coupling HARD-COUP-635X8 16 Nylon Insert Hex Locknut M5 HARD-NUT-LOCK-5MM 75 Tee Nuts – 1 Piece HARD-TNUT-M5-1 4 V-Slot 20 x 40mm – 1000mm LR-2040-S-1000 2 V-Slot 20 x 80mm – 250mm LR-2080-S-250 3 C-Beam – 1000mm LR-C-S-1000 1 C-Beam – 250mm LR-C-S-250 2 Joining Plates – 5 Hole 90 degree PLATE-90-5 8 C-Beam End Mount PLATE-C-END 7 C-Beam Gantry Plate – XL PLATE-C-GANTRY-XL 32 M5 Low Profile Screws – 10mm SCREWS-M5-LP-10-1 46 M5 Low Profile Screws – 20mm SCREWS-M5-LP-20-1 4 M5 Low Profile Screws – 30mm SCREWS-M5-LP-30-1 2 M5 Low Profile Screws – 55mm SCREWS-M5-LP-55-1 18 M5 Low Profile Screws – 60mm SCREWS-M5-LP-60-1 60 M5 Low Profile Screws – 8mm SCREWS-M5-LP-8-1 14 Eccentric Spacers – 8mm Hex – 6mm Height SHIM-ECCENTRIC-8-6 14 Metric Aluminum Spacers – 3mm SHIM-SPAC-3MM 8 Metric Aluminum Spacers – 40mm SHIM-SPAC-40MM 20 Metric Aluminum Spacers – 6mm SHIM-SPAC-6MM 12 Metric Aluminum Spacers – 9mm SHIM-SPAC-9MM 28 Solid V Xtreme Wheel Kit WHEEL-XTREME-SOLID-V-KIT 6 Thrust Bearings BEAR-F8-16M Lead CNC X-Axis Cable Chain Extrusion Bill of Materials QTY Description Part Number 1 V-Slot 20 x 40mm – 1000mm LR-2040-S-1000 2 Universal L Brackets – Single BRAC-L1 2 M5 Low Profile Screws – 8mm SCREWS-M5-LP-8-1 2 M5 Low Profile Screws – 15mm SCREWS-M5-LP-15-1 2 Metric Aluminum Spacers – 9mm SHIM-SPAC-9MM 2 Drop In Tee Nut HARD-TNUT-DROP 2 T-Nuts – 1 Piece HARD-TNUT-M5-1 1 End Cap – 2040 BRAC-ENDCAP-2040   NOTE: Base/waste board is NOT included.
